Enviroquip^® Belt Press Filter

Built for the most demanding municipal and industrial applications, the Enviroquip Belt Press Filter line is a comprehensive solution for sludge dewatering applications. Three different models, in three different sizes, allow design flexibility to fit a wide variety of plant capacity requirements, available footprints, and other design-related constraints.

The system combines durability and high-performance, which can significantly reduce handling costs and waste disposal volumes. Other important features and benefits include:

• Solid frame mechanisms are constructed of high strength tubular and structure steel members for longevity
• Corrosion resistant 304 or 316 stainless steel construction available, as well as hot dipped galvanised material
• Fully adjustable wedge zone system
• Dual belt design with individual belt drives, complete with belt tracking systems to ensure proper belt performance

All machines are available in widths of 1.2, 1.7 and 2.2 m (3.9, 5.6, 7.2 ft) and contain a fully adjustable wedge (or gravity) zone (where the two belts come together) and pressure zone (typically through 8 or more rollers). Series 4 and 5 presses begin the pressure zone with a 914 mm (36 in) perforated roller.

• Series 3 machines possess a gravity zone from 3.3 to 6.3 m² (36 to 68 sq ft) and up to 117 PSI in the pressure zone (2.2 metres or 7.2 ft)
• Series 4 machines have a gravity zone from 4.4 to 8.4 m² (47 to 90 sq ft) and attain up to 152 PSI in the pressure zone (2.2 metres or 7.2 ft)
• Series 5 machines have a gravity zone from 5 to 9.7 m² (54 to 104 sq ft) and attain up to 174 PSI in the pressure zone (2.2 metres or 7.2 ft)
