Brackett Green® S.I.M.P.L.E.® Fish Handling Screen

S.I.M.P.L.E.® fish screens are supplied as dual flow, dual flow conversion and thru-flow models. The unique design provides for the natural tendency of juvenile fish to seek shelter in the integrated buckets when caught in the flow of an intake. The screen rotates the fish to deck level where a series of gentle sprays channels the fish into a trough, then back to their source water. The Brackett Green® S.I.M.P.L.E® fish handling screen is in compliance with EPA regulation 316b.
  • Meets increasing demand for marine life conservation worldwide
  • Safeguards the future of fish
  • Handles most types and sizes of fish
  • Increases fish survivability for new and existing water intakes
  • Effective low pressure spray protects fish

Ovivo offers some of the world’s leading technologies in fish protection. The S.I.M.P.L.E.® fish handling band screen is one such innovation. Utilizing a “recovery and return” approach, traveling fish buckets are incorporated into existing or new rotating band and drum screens. Captured fish are elevated to deck level in a pool of water retained in the bucket, where a series of gentle sprays sluice the fish into a return trough, back to their natural habitat and away from the intake flow. This advanced process has proven to be both reliable and effective, ensuring significant increases in marine life survival at raw water intakes.

In addition to helping plants meet the requirements of US EPA Legislation 316(b), the S.I.M.P.L.E.® fish screens are available in dual flow, dual flow conversions or thru-flow configurations and can be designed to accommodate various flow rates, high water, low water and invert. Various mesh openings and construction materials can be selected for fresh, brackish or seawater intakes.

  • Retrofit to existing band and drum screens
  • Helps to meet the requirements of the US EPA regulation 316(b) and the recommendations of the UK’s best practice guide
  • Significantly reduces trash handling and disposal costs through a decrease in fish kills
  • Helps eliminate plant outages due to inundation by large shoals of fish

Responding to increasing demands to reduce the environmental impacts of cooling water withdrawal on new or existing intakes, Ovivo now manufactures fish handling band screens using the S.I.M.P.L.E.® process for marine life recovery.

The S.I.M.P.L.E.® screen is designed to recover and return fish to their natural habitat unharmed, thereby increasing fish survivability and lowering the costs associated with unplanned shutdowns due to large numbers of fish being drawn into intakes and fouling equipment, along with the costs of disposing the captured fish.

The screens are available in a multitude of different materials, including epoxy-coated or galvanized carbon steel, with stainless smooth-top or non-metallic mesh. For inquiries, please specify flow rate, high water, low water, desired mesh opening, elevations or height of deck, number of screens required and desired construction material. Our engineers can also customize the screen components to fit existing band and drum screens.


Juvenile fish that meet the traveling screens naturally seek the shelter of the integrated fish bucket due to the stabilized flow. The traveling screen rotates the fish to deck level where a series of sprays gently channel the fish into a trough and back to their source water, away from the intake.

The success of the S.I.M.P.L.E.® fish recovery and return system as earned a BAT (Best Available Technology) approval rating and the recommendations of the UK’s best practice guide. It also helps plants meet the requirements of the US EPA regulation 316(b).

What are the survival rates of the fish captured?

A complete general information package including survival reports is available upon request.

contact us

Ovivo sells Fish Guidance Systems under its own trademark incorporating traveling water screen basket equipment under a license agreement. For further information about the availability of this product, please contact our Customer Contact Center.
