Ovivo® Silicon Carbide (SiC) Flat Plate Membranes

KEY ADVANTAGES:

  • Highest Flux
  • Withstands the Harshest Environments
  • Quick & Easy Cleaning for Full Recovery
  • Longest Life of Any Membrane



Immersed Ceramic Silicon Carbide (SiC) Flat Sheet Immersed Ceramic Silicon Carbide (SiC) Flat Sheet
SiC Ceramic Flat Sheet Membrane filtration SiC Ceramic Flat Sheet Membrane filtration

High Flux MBR

  • Allows for operation at high mixed liquor suspended solids (MLSS)
  • Increases capacity of microBLOX® units in the same small footprint

Sludge Thickening

  • Expand the operating window for membrane thickener (MBT)
  • Repels negatively charged particles including fats, oils & grease
  • Easier to recover from dewatering

Wet Weather Systems

  • Ideal solution for Combined Sewage Overflow (CSO), Sanitary Sewer Overflows (SSO) MBR peak flow, Conventional Activated Sludge (CAS)
  • SiC membranes can be completely dried, and easily endure peak flows needed in intermittent storm use

Tertiary Treatment

  • High flux, low footprint design with lower energy consumption

Semiconductor Wastewater Treatment

  • Lowest foot print for any FSM technology
  • Modules individually replaceable
  • Flexible design for easy add or removal of single module

KEY FEATURES & BENEFITS:

Feature

Benefit
0.1 micron pore size
  • Robust and durable physical barrier to suspended solids and pathogens, providing the highest effluent quality over the life of the membrane.
Completely hydrophilic
  • Highest Membrane Flux
  • Unmatched low footprint
  • High Recovery Rates
  • Low pressure operation at high flow
Chemically inert
  • Can operate in extreme environments
  • Extremely durable & reliable operation
Negatively charged
  • Repels negatively charged foulants, making membrane less prone to fouling and clogging
  • Allows for less maintenance equipment

OVIVO® SiC FLAT PLATE MEMBRANE CONFIGURATIONS:

OPERATING LIMITS/CAPABILITIES:

Operating Parameter
Units
 Silicon Carbide
TSS mg/l < 45, 000
Oil & Grease mg/l < 500
Free Oil mg/l < 500
pH – 1-14
Temperature °C 1-80
Backwash Pressure psi < 30
Chlorine Tolerance wt% 1
